ROUTER 2.4GHz 300Mbps MERCUSYS MW302R MULTIMODO

WirelessWireless Standards
IEEE 802.11b/g/n

Frequency
2.4-2.4835GHz

Signal Rate
• 11n: Up to 300Mbps (Dynamic)
• 11g: Up to 54Mbps (Dynamic)
• 11b: Up to 11Mbps (Dynamic)

Reception Sensitivity
• 270M: -73dBm@10% PER
• 130M: -75dBm@10% PER
• 54M: -77dBm@10% PER
• 11M: -90dBm@10% PER
• 6 M: -94dBm@10% PER
• 1 M: -96dBm@10% PER

Transmission Power
<20dBm (EIRP)

Wireless Security
WPA-PSK / WPA2-PSK

Wireless Functions
Enable/Disable Wireless Radio, WDS Bridging

SoftwareWAN Type
Dynamic IP/Static IP/PPPoE/PPTP/L2TP

Management
Access Control, Local Management, Remote Management

DHCP
Server

Port Forwarding
Virtual Server, UPnP, DMZ

Firewall Security
IP and MAC Address Binding

Protocols
IPv4, IPv6

Guest Network
2.4GHz Guest Network

HardwareDimensions (W X D X H)
114 mm × 94 mm × 26 mm

Button
Reset Button

External Power Supply
5V/0.6A

Antenna Type
2 * 5dBi

Ethernet Ports
2*10/100Mbps LAN Ports &
1*10/100Mbps WAN Port

OthersPackage Contents
300Mbps Wireless N Router ( MW302R )
Power Adapter
Quick Installation Guide
Ethernet Cable

Environment
• Operating Temperature: 0°C~40°C (32°F~104°F)
• Storage Temperature: -40°C~70°C (-40°F~158°F)
• Operating Humidity: 10%~90% Non-Condensing
• Storage Humidity: 5%~90% Non-Condensing
